18 LED DRIVING LAMP LIGHTBAR SPOT BEAM 9-36V 90W 8,100Lmns
$139.22
18 LED DRIVING LAMP LIGHTBAR SPOT BEAM 9-36V 90W 8,100Lmns
Contains 1 Items
Product Description
Ignite Ultra Slimline Single Row LED Driving Lamp Lightbar 9 - 36 Volt 90 Watt
- 15° Spot (Pencil) Beam Pattern
- 18 x 5 Watt High Intensity LG LED's
- 8,100 Raw and 6,950 Effective Lumens and 6,500K
- 1 Lux @ 448m and 165,625cd Peak Beam Intensity
- Current Draw: 6.2amp @ 12 Volt and 2.8amp @ 24 Volt
- Polycarbonate Reflector Focusing Optic Drive Technology with Lexan Polycarbonate Lens
- Light Transmittance >95%
- Integrated Electronic Thermal Management (ETM)
- Black Anodized Polyester Powder coated Extruded 6063 Aluminium Housing with integrated Heat-Sink and Pressure Equalising Vent
- Dual Mounting Systems; 6063 Aluminium Bottom Mount Brackets and SUS201 Stainless Steel Side Mount Brackets
- Cross slider bracket assembly allows the Bottom Brackets to be positioned anywhere along bars length
- 500mm Lead with 2 Pin Deutsch Plug
- Over and Under Voltage Protection
- Reverse Polarity Protection
- UV, Water and Shock resistant
- Anti Rust, corrosion and freezing resistance
- 50,000 Hours LED Lifespan
- ECE R112 (Ref 45), R10 and CE Approved
- IP68 and IP69K Rating
- Environment Temperature: -40°C ~ +60°C
- Weight: 1.12kg
Specifications
| Specification | Details |
|---|---|
| Series | Other |
| Type | LED |
| Voltage | Multivolt |
| Watts | Other |
| Beam Type | Spot |
| Rows | Single |
| No. of LED | 18 |
| Mount | Other |
| SKU | ILB604 |
| Brand | IGNITE |
| Unit Of Measure | ea |
