Ultra Slimline Single Row 27 LED Dual Colour Lightbar Driving Beam 9-36V 216W

Contains 1 Item

Product Description

Ignite Ultra Slimline Single Row Dual Colour LED Driving Lamp Lightbar 9 - 36 Volt 216 Watt

• Dual White and Amber Illumination - user selectable
• 40° Driving Beam Pattern
• 18 x 8 Watt High Intensity White LP LED's and 9 x 8 Watt High Intensity Amber LP LED's
• 15,000 Raw and 13,000 Effective Lumens and 6,000K on White Illumination
• 7,200 Raw and 6,100 Effective Lumens and 3,200K on Amber Illumination
• 1 Lux @ 595m and 355,000cd Peak Beam Intensity on White Illumination
• 1 Lux @ 361m and 130,300cd Peak Beam Intensity on Amber Illumination
• Current Draw: 8.3amp @ 12 Volt and 4.0amp @ 24 Volt on White Illumination
• Current Draw: 5.3amp @ 12 Volt and 2.5amp @ 24 Volt on Amber Illumination
• Polycarbonate Reflector Focusing Optic Drive Technology with Lexan Polycarbonate Lens
• Integrated Electronic Thermal Management (ETM)
• Black Anodized Polyester Powder coated Extruded 6063 Aluminium Housing with integrated Heat-Sink and Pressure Equalising Vent
• Dual Mounting Systems; 6063 Aluminium Bottom Mount Brackets and SUS201 Stainless Steel Side Mount Brackets
• Cross slider bracket assembly allows the Bottom Brackets to be positioned anywhere along bar's length
• 500mm Lead with 2 Pin Deutsch Plug
• Over and Under Voltage Protection
• Reverse Polarity Protection
• UV, Water and Shock resistant to 15G
• Anti Rust, corrosion and freezing resistance
• 50,000 Hours LED Lifespan
• ECE R10 and CE Approved
• IP68 and IP69K Rating
• Environment Temperature: -40°C ~ +60°C
• Weight: 9kg
